Automatic Psa Oxygen Plant Oxygen Concentrator

Product Description

Automatic Psa Oxygen Plant Oxygen Concentrator

The compressed air passes through the air purification system to remove the impurities, such as oil, water and dust, and into the adsorption tower with zeolite molecular sieve. The nitrogen, carbon dioxide and water vapor in the air are adsorbed in large quantities by molecular sieves, and oxygen and nitrogen are separated because of the high diffusion rate of oxygen.

Oxygen Production Equipment and Nitrogen Production Equipment are selling hot. We also have SMT cleaning machine, SMT nozzle and SMT feeder for sale. please contact us if you need.

The main products of ROC: SMT Cleaning Machine, PSA oxygen / nitrogen generator, wafer cleaning equipment, PCBA Cleaning Machine, SMT Nozzle etc. If there is any need, please contact us.

1. Equipment Installation Condition







Power for Oxygen Generator



Power for Heatless Air Dryer

Environment Temperature

≤38℃(good ventilation)


Gas(PSA gas consumption)


≥ 0.77Nm3/min


Air Compressor Output Requirements


≥ 0.7MPa


≤ 50 ℃

Oil Content

≤ 3 PPm

Dust Size

≤ 5 μm

2. Oxygen Generator Specification

oxygen capacity 2-200Nm3/h
oxygen purity 93%+-2%
output pressure 0.1-0.5MPa(1-5Bar) adjustable / 15MPa filling pressure offered

Specification output (Nm³/h) Effective gas consumption (Nm³/h) air cleaning system
CBO-5 5 0.95 KJ-1
CBO-10 10 2.1 KJ-2
CBO-20 20 4.0 KJ-6
CBO-40 40 8.2 KJ-10
CBO-60 60 12.3 KJ-12
CBO-80 80 16.3 KJ-20
CBO-100 100 20.8 KJ-20
CBO-150 150 30.7 KJ-30
CBO-200 200 41 KJ-40

Oxygen Generator Machine Feature Oxygen Gas Plant PriceOxygen Gas Manufacturing Plant CostMedical Oxygen Gas Generation PlantGas Oxygen Generator

3. Process Flow Brief Description

 Oxygen Pressure Swing Adsorption

4.Technical Features

1).Full Automation

All systems are designed for un-attended operation and automatic Nitrogen demand adjustment.

2).Lower Space Requirement

The design and Instrument makes the plant size very compact,assembly on skids,prefabricated from factory.

3).Fast Start-up

Start-up time is only 5 minutes to get desired Nitrogen purity.So these units can be switched ON&OFF as per Nitrogen demand changes.

4).High Reliabiity

Very reliable for continuous and steady operation with constant Nitrogen purity.Plant availability time is better than 99% always.

5).Molecular Sieves life

Expected Molecular sieves life is around 15-years i.e. whole life time of nitrogen plant.So no replacement costs.


By altering flow,you can deliver nitrogen with precisely the right purity.

Send Inquiry Please bring the following description, we have more models to recommend to you ~! Thank you~!

Technical Information Your Kind Requirement


Purity _________%
Outlet Pressure _________Mpa or Bar
Power ________V/HZ
Oxygen Generator Plants

Contact us if you need more details on Oxygen Generator Systems. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Oxygen Generation System、Hospital Oxygen Machine. If these products fail to match your need, please contact us and we would like to provide relevant information.
