High Quality Durable Using Various Pl-6018i Ultrasound Scanner Portable Color Doppler Ultrasound
Product Description
Products Description
Warranty Service | 1 year |
After-sales service | Online technical support |
Origin | Jiangsu, China |
Model | MP-6 |
Product name | Color Doppler Ultrasound Scanner |
Factory price electric laptop color doppler cheap hospital Ultrasound scanner
Technical Specification:
-Monitor : 15” high-resolution LCD color monitor
-Gray scale : 256
-Scanning lines : ≥256
-Dynamic Range : 30dB-75dB
-Maximum frame rate : ≥65/s
-Pseudo-color display : 11
-Note: body mark and character note, body mark: ≥100
-Cine loop : ≥100 frame
-Image memory : ≥160G, format BMP/JPG/DCM/TIF
-TGC : ≥8
-Partial enlarged : ≥ 4 times
-Image mode: B, BB, 4B, B+M , M, PWD, PwrD, CD, CWD, DirPwr, B+C+D.
-Image processing : 8 frame-related, 6 related to six-speed lines
-Image flip : up and down , left and right , image rotation ( 2B, 4B mode rotated 90 ° ) , black and white
-DICOM3.0 interface with network remote assistance software
-Sampling frame size, position and color : support B / color consistent width adjustable
-Pulse repetition frequency : 0.5-2khz , 6 adjustable
-Gain : 20dB-48dB , grading adjustable
-Wall filter : 40-500 adjustable
-Noise Reduction : 32 adjustable
-Sample volume : 0.5-10mm adjustable range 20
-Scan speed : 8 adjustable
-Support synchronous updates automatically trace and spectral inversion
-Baseline position, spectrum volume and correction angle : adjustable
-Blood flow measurement velocity:
a) Maximum blood flow velocity measurement : pulse doppler > 2m/s
b) Lowest measured blood flow velocity : <2mm /s (non-noise signals)
-Port and holder: 4 activated probe ports and holders, 1 Gel heater holder
-Input / Output Interface : USB2.0 , LAN , VGA , RS232 , Video, DICOM3.0, foot switch, XGA, DVD burner
Measurement:
-Mode B (2D) measurement
a) General measurement: distance, perimeter, area, volume, distance narrower radio, area stenosis ratio.
b) Gynecological measurement: uterine size and volume, cervix size and volume, right/left ovary size and volume, endometrial thickness, right/left follicle volume.
-M mode measurements: distance, heart rate.
-Doppler measurements: General measurement: systolic and end-diastolic velocity, peak flow, time, blood flow, pulse index and heart rate.
Standard Configuration:
-Scanner Body: 1pc
-3.5Mhz Convex Probe: 1pc
-Charger with a Set of Wires: 1set
-Bottle of USG gel: 1pc
-User Manual: 1pc
Optional:
-Micro-convex probe
-Phased array probe
-Trans-virginal probe
-Linear probe
-Printer
-Monitor : 15” high-resolution LCD color monitor
-Gray scale : 256
-Scanning lines : ≥256
-Dynamic Range : 30dB-75dB
-Maximum frame rate : ≥65/s
-Pseudo-color display : 11
-Note: body mark and character note, body mark: ≥100
-Cine loop : ≥100 frame
-Image memory : ≥160G, format BMP/JPG/DCM/TIF
-TGC : ≥8
-Partial enlarged : ≥ 4 times
-Image mode: B, BB, 4B, B+M , M, PWD, PwrD, CD, CWD, DirPwr, B+C+D.
-Image processing : 8 frame-related, 6 related to six-speed lines
-Image flip : up and down , left and right , image rotation ( 2B, 4B mode rotated 90 ° ) , black and white
-DICOM3.0 interface with network remote assistance software
-Sampling frame size, position and color : support B / color consistent width adjustable
-Pulse repetition frequency : 0.5-2khz , 6 adjustable
-Gain : 20dB-48dB , grading adjustable
-Wall filter : 40-500 adjustable
-Noise Reduction : 32 adjustable
-Sample volume : 0.5-10mm adjustable range 20
-Scan speed : 8 adjustable
-Support synchronous updates automatically trace and spectral inversion
-Baseline position, spectrum volume and correction angle : adjustable
-Blood flow measurement velocity:
a) Maximum blood flow velocity measurement : pulse doppler > 2m/s
b) Lowest measured blood flow velocity : <2mm /s (non-noise signals)
-Port and holder: 4 activated probe ports and holders, 1 Gel heater holder
-Input / Output Interface : USB2.0 , LAN , VGA , RS232 , Video, DICOM3.0, foot switch, XGA, DVD burner
Measurement:
-Mode B (2D) measurement
a) General measurement: distance, perimeter, area, volume, distance narrower radio, area stenosis ratio.
b) Gynecological measurement: uterine size and volume, cervix size and volume, right/left ovary size and volume, endometrial thickness, right/left follicle volume.
-M mode measurements: distance, heart rate.
-Doppler measurements: General measurement: systolic and end-diastolic velocity, peak flow, time, blood flow, pulse index and heart rate.
Standard Configuration:
-Scanner Body: 1pc
-3.5Mhz Convex Probe: 1pc
-Charger with a Set of Wires: 1set
-Bottle of USG gel: 1pc
-User Manual: 1pc
Optional:
-Micro-convex probe
-Phased array probe
-Trans-virginal probe
-Linear probe
-Printer
